Min. Order: 5,000 Square Meters
Port: Xiaolan, China
Production Capacity: 250 Million Square Meters Per Year
Payment Terms: T/T
Application: Insulators, Electrical Winding Insulation, Winding Wire Coating Insulation
Type: Insulation Tape
Chemistry: Inorganic Insulation
Material: PVC
Thermal Rating: 0-60
Maximum Voltage: 5kv~6kv
Basic Info
Model NO.: pvc electrical tape Classification: Inorganic Insulation Material Certification: UL, ISO9001 Color: Black, Red, Yellow, Blue, Green, White Brand: Yong Yi Total Thickness: 0.13mm and 0.18mm Usable Width for Log Size: 1250mm Trademark: YONG YI Transport Package: 1 PCS/Wrapper, 10PCS/Shrink-Wrap, 200~500PCS/CTN Specification: 1250mm*18.2m/9.1m/7.3m or 18mm*18.2m/9.1m/7.3m Origin: China HS Code: 39199090
Product Description
Model: EI110-GH
Backing: Soft PVC film.
Backing thickness: 110± 6um
Total thickness: 0.13± 0.01mm
Tensile strength: (TD)- - ≥ 12(N/cm)
Elongation at break: ≥ 180%
Feature: Good flexibility and high tensile strength.
Adhesive: Rubber type pressure sensitive adhesive.
Rolling tack≥ 12#
Adhesive strength≥ 2 N/25mm
Dielectric strength≥ 5KV/min
Suggested Application: Used for insulating packing of electric wire.
Storage: One year under the condition of 23º C and 50%RH.
Note: The information submitted is based on our current knowledge and experiment.
