Use of double-sided adhesive for printing board.
Adhesive Encyclopedia / 2018-08-11



1,before we paste the plate, we place the plate material, tape and plate roller at the same room temperature for a period of time.


2, before the paste plate, must make the plate and plate roller clean.


3, if the plate on the sleeve, must use the minimum air pressure to prevent sleeve deformation.


4, double-sided tape joint should be staggered with the plate joint.


5, when adhesive tape, it is best to use a rubber scraper to apply the adhesive tape evenly to the drum in a parallel sweep manner, and no bubbles can be left between the duct tape and the plate roll; (If bubble retention applies needle puncture elimination).


6, before determining the position of the printing plate, should avoid the printing plate and tape contact prematurely, after determining the printing position, remove the tape protection layer side of the printing plate with a rubber roll on the tape in a parallel sweep.


7, in the printing process to clean printing plate, should avoid cleaning solvent contact tape, so as not to damage the tape.


8,the angle between the plate and the tape should not be more than 90 degrees when the plate is removed from the tape.


9, the place where the version of the interface is left about 5mm, use 3M 1600 electrical insulation tape seal plate effect is good, can effectively avoid rubbing the plate caused by the ink pollution caused by the interface, and it is very economical.


10,overuse of double-sided glue can lead to poor overprinting, especially when there is a new change in a set of releases and it is easy to occur when it is used for a long time.
